Horizon Power and Data Module

  • Fusion silver finish with flame retardant ABS signal grey RAL7004 socket fascia’s
  • Module lifts and locks proud of the desk surface
  • Lid retracts to allow access from both sides - suitable for conference tables
  • Fitting from above, locks into position using two screws
  • Spring loaded buttons lock module proud of desk surface and on release allows module to retract below desk surface
  • Available with power, data and USB configurations to suit individual client needs
  • All UK power socket versions feature individual fuses
  • Choice of 3.15A or 5A fuses are available to comply with BS 6396:2008
  • Unit complies with BS 5733
  • Supplied with a 3m lead to 13A UK plug and 3m data lead where relevant

Product information

Horizon power and data module is a through desk module that sits flush to the desk. The housing hides the power sockets until they are required, when the lid can be retracted and the power sockets can be pulled up to desk level where the spring loaded button locks the power module in place.



Product Options

Horizon is capable of hosting a variety of power and data sockets including:

  • 5 Amp USB Charger
  • International power sockets
  • USB data transfer
  • HDMI
  • VGA
  • Choice of 3.15A or 5A fuses are available

Fixing

Safety

  • Fusion silver finish with flame retardant ABS Grey socket fascias
  • All UK power socket versions feature individual fuses
  • Complies with BS 6396
  • Unit complies with BS 5733





Notes

  • Cables: White and grey modules are supplied with white cables and black modules are supplied with black cables.
  • Data Cables: CMD cannot accept any responsibility or liability for providing category 6 performance in products supplied. CMD cannot accept any responsibility or liability for providing HDMI performance in products supplied over 5m in length.
  • Fuses: Only accessible after removal of equipment plug.
  • Lead Lengths: All lead lengths are approximate and subject to tolerance. Lead lengths shown will be the conductor length and not the distance from the end of the module to the plug. For example, a 3m prewired power lead will be approximately 2.875m as 125mm will be internal for the termination. This is also applicable for data leads.
  • Data fascias may be subject to colour change.

Standard Products

UK CodeSchuko CodeColourDescription
96H066Grey Fascias
Fusion Silver Body
2 x UK Power, 2 x RJ45, 1 x VGA, 1 x 3.5 Mini Jack
96H067Grey Fascias
Fusion Silver Body
2 x UK Power, 2 x RJ45, 1 x VGA, 1 x HDMI, 1 x Mini Jack
96U123Grey Fascias
Fusion Silver Body
4 x UK Power, 2 x RJ45
96U122Grey Fascias
Fusion Silver Body
2 x UK Power, 2 x RJ45
96P044Grey Fascias
Fusion Silver Body
2 x UK Power
96P045Grey Fascias
Fusion Silver Body
4 x UK Power

2 x UK Power, 2 x RJ45, 1 x VGA, 1 x 3.5 Mini Jack

UK Part Number: 96H066

  • Sockets individually fused to 3.15A
  • CAT6 Data Sockets
  • 3m Mains lead to 13A UK Plug
  • 3m Data leads to relevant plug

Colour

Grey Fascias
Fusion Silver Body

2 x UK Power, 2 x RJ45, 1 x VGA, 1 x HDMI, 1 x Mini Jack

UK Part Number: 96H067

  • Sockets individually fused to 3.15A
  • CAT6 Data Sockets
  • 3m Mains lead to 13A UK Plug
  • 3m Data leads to relevant plug

Colour

Grey Fascias
Fusion Silver Body

4 x UK Power, 2 x RJ45

UK Part Number: 96U123

  • Sockets individually fused to 3.15A
  • CAT6 Data Sockets
  • 3m Mains lead to 13A UK Plug
  • 3m Data leads to relevant plug

Colour

Grey Fascias
Fusion Silver Body

2 x UK Power, 2 x RJ45

UK Part Number: 96U122

  • Sockets individually fused to 3.15A
  • CAT6 Data Sockets
  • 3m Mains lead to 13A UK Plug
  • 3m Data leads to relevant plug

Colour

Grey Fascias
Fusion Silver Body

2 x UK Power

UK Part Number: 96P044

  • Sockets individually fused to 3.15A
  • 3m Mains lead to 13A UK Plug

Colour

Grey Fascias
Fusion Silver Body

4 x UK Power

UK Part Number: 96P045

  • Sockets individually fused to 3.15A
  • 3m Mains lead to 13A UK Plug

Colour

Grey Fascias
Fusion Silver Body
