Porthole Power, USB Charging, Data & Media

  • Available in three colours: black, white and grey. with a matching trim
  • Fits in to standard 80mm grommet hole
  • Designed to fit any desk thickness between 13mm - 50mm
  • Available with a choice of power including USB Charging, data/media (USB data transfer, HDMI and 3.5mm Audio Mini Jack) sockets giving excellent versatility for the user
  • Wireland starter cable required for this product
  • Individually fused socket, independently certified to BS 5733
  • Fully segregated power and data
  • Compliance capability with BS 6936
  • Complies with charging standard (BS EN 62684) for data enabled mobile phones
  • Option for 2 independent USB charging ports

Product information

Porthole power and data module converts any 80mm grommet hole into an through desk power and data solution. With a stylish and compact design, Porthole is the perfect choice for space saving installations, discreet power solutions  (Porthole can be installed into ‘soft furnishings’) or hot desking environments.



Product Options

The module is supplied with 1 x UK power socket as standard, but has the option to add in:

  • USB charging
  • USB data transfer
  • HDMI
  • Data
  • 3.5mm Audio Jack

Available in three colours: Black, White or Grey, with a matching finished trim.



Fixing

Porthole is simple to install. If you have an existing 80mm grommet hole in your desk simply place the barrel of the module into the grommet hole and use the barrel nut (103.5mm diameter) to secure the unit to the desk.



Safety

  • Individually fused sockets (Choice of either 3.15A or 5A)
  • Lip ensures that spillages cannot enter the module.
  • 1m Mains lead to 3 pole connector (Suitable for connecting to an Elite+ under desk power module)
  • Independently certified to BS 5733
  • Suitable for use in BS6396 installations





Notes

  • Cables: White and grey modules are supplied with white cables and black modules are supplied with black cables.
  • Data Cables: CMD cannot accept any responsibility or liability for providing category 6 performance in products supplied. CMD cannot accept any responsibility or liability for providing HDMI performance in products supplied over 5m in length.
  • Fuses: Only accessible after removal of equipment plug.
  • Lead Lengths: All lead lengths are approximate and subject to tolerance. Lead lengths shown will be the conductor length and not the distance from the end of the module to the plug. For example, a 3m prewired power lead will be approximately 2.875m as 125mm will be internal for the termination. This is also applicable for data leads.
  • Data fascias may be subject to colour change.

Standard Products

UK CodeSchuko CodeColourDescription
90P100007GSTBlack/Black Surround1 x UK Power Socket Power socket 3.15A individually fused with 1m mains lead to 3 Pole connector
90P100008GSTGrey/Grey Surround1 x UK Power Socket Power socket 3.15A individually fused with 1m mains lead to 3 Pole connector
90P125417GSTWhite/White Surround1 x UK Power Socket Power socket 3.15A individually fused with 1m mains lead to 3 Pole connector
90PD90878GSTBlack/Black Surround1 x UK Power Socket, 1 x RJ45 Cat6 Socket Power socket 3.15A individually fused with 1m mains lead to 3 Pole connector and 3m data lead
90PD100001GSTGrey/Grey Surround1 x UK Power Socket, 1 x RJ45 Cat6 Socket Power socket 3.15A individually fused with 1m mains lead to 3 Pole connector and 3m data lead
90PD100002GSTWhite/White Surround1 x UK Power Socket, 1 x RJ45 Cat6 Socket Power socket 3.15A individually fused with 1m mains lead to 3 Pole connector and 3m data lead
90PD102253GSTBlack/Black Surround1 x UK Power Socket, 2 x RJ45 Cat6 Sockets Power socket 3.15A individually fused with 1m mains lead to 3 Pole connector and 2 x 3m data leads
90AV97745GSTGrey/Grey Surround1 x UK Power Socket, 2 x RJ45 Cat6 Sockets Power socket 3.15A individually fused with 1m mains lead to 3 Pole connector and 2 x 3m data leads
90PD105196GSTWhite/White Surround1 x UK Power Socket, 2 x RJ45 Cat6 Sockets Power socket 3.15A individually fused with 1m mains lead to 3 Pole connector and 2 x 3m data leads
90AV100001GSTBlack/Black Surround1 x UK Power Socket, 1 x USB Socket (Data transfer) Power socket 3.15A individually fused with 1m mains lead to 3 Pole connector and 2m USB lead
90AV100002GSTGrey/Grey Surround1 x UK Power Socket, 1 x USB Socket (Data transfer) Power socket 3.15A individually fused with 1m mains lead to 3 Pole connector and 2m USB lead
90AV100003GSTWhite/White Surround1 x UK Power Socket, 1 x USB Socket (Data transfer) Power socket 3.15A individually fused with 1m mains lead to 3 Pole connector and 2m USB lead
90AV95978GSTBlack/Black Surround1 x UK Power Socket, 2 x USB Sockets (Data transfer) Power socket 3.15A individually fused with 1m mains lead to 3 Pole connector and 2 x 2m USB leads
90AV100004GSTGrey/Grey Surround1 x UK Power Socket, 2 x USB Sockets (Data transfer) Power socket 3.15A individually fused with 1m mains lead to 3 Pole connector and 2 x 2m USB leads
90AV94022GSTWhite/White Surround1 x UK Power Socket, 2 x USB Sockets (Data transfer) Power socket 3.15A individually fused with 1m mains lead to 3 Pole connector and 2 x 2m USB leads
90AV100005GSTBlack/Black Surround1 x UK Power Socket, 1 x RJ45 Cat6 Socket, 1 x USB Socket (Data transfer) Power socket 3.15A individually fused with 1m mains lead to 3 Pole connector, 3m data lead and 2m USB lead
90AV100006GSTGrey/Grey Surround1 x UK Power Socket, 1 x RJ45 Cat6 Socket, 1 x USB Socket (Data transfer) Power socket 3.15A individually fused with 1m mains lead to 3 Pole connector, 3m data lead and 2m USB lead
90AV82656GSTWhite/White Surround1 x UK Power Socket, 1 x RJ45 Cat6 Socket, 1 x USB Socket (Data transfer) Power socket 3.15A individually fused with 1m mains lead to 3 Pole connector, 3m data lead and 2m USB lead
Data Cables
1617133m Cat 6 data cable. Male to male connector.
1612392m USB data cable. Male to male connector.
1617182m HDMI data cable. Male to male connector.

1 x UK Power Socket Power socket 3.15A individually fused with 1m mains lead to 3 Pole connector

UK Part Number: 90P100007GST

  • Socket individually fused to 3.15A
  • 1m Mains lead to 3 pole connector

Colour

Black/Black Surround

1 x UK Power Socket Power socket 3.15A individually fused with 1m mains lead to 3 Pole connector

UK Part Number: 90P100008GST

  • Socket individually fused to 3.15A
  • 1m Mains lead to 3 pole connector

Colour

Grey/Grey Surround

1 x UK Power Socket Power socket 3.15A individually fused with 1m mains lead to 3 Pole connector

UK Part Number: 90P125417GST

  • Socket individually fused to 3.15A
  • 1m Mains lead to 3 pole connector

Colour

White/White Surround

1 x UK Power Socket, 1 x RJ45 Cat6 Socket Power socket 3.15A individually fused with 1m mains lead to 3 Pole connector and 3m data lead

UK Part Number: 90PD90878GST

  • Socket individually fused to 3.15A
  • 1m Mains lead to 3 pole connector
  • 3m Data lead

Colour

Black/Black Surround

1 x UK Power Socket, 1 x RJ45 Cat6 Socket Power socket 3.15A individually fused with 1m mains lead to 3 Pole connector and 3m data lead

UK Part Number: 90PD100001GST

  • Socket individually fused to 3.15A
  • 1m Mains lead to 3 pole connector
  • 3m Data lead

Colour

Grey/Grey Surround

1 x UK Power Socket, 1 x RJ45 Cat6 Socket Power socket 3.15A individually fused with 1m mains lead to 3 Pole connector and 3m data lead

UK Part Number: 90PD100002GST

  • Socket individually fused to 3.15A
  • 1m Mains lead to 3 pole connector
  • 3m Data lead

Colour

White/White Surround

1 x UK Power Socket, 2 x RJ45 Cat6 Sockets Power socket 3.15A individually fused with 1m mains lead to 3 Pole connector and 2 x 3m data leads

UK Part Number: 90PD102253GST

  • Socket individually fused to 3.15A
  • 1m Mains lead to 3 pole connector
  • 3m Data lead

Colour

Black/Black Surround

1 x UK Power Socket, 2 x RJ45 Cat6 Sockets Power socket 3.15A individually fused with 1m mains lead to 3 Pole connector and 2 x 3m data leads

UK Part Number: 90AV97745GST

  • Socket individually fused to 3.15A
  • 1m Mains lead to 3 pole connector
  • 3m Data lead

Colour

Grey/Grey Surround

1 x UK Power Socket, 2 x RJ45 Cat6 Sockets Power socket 3.15A individually fused with 1m mains lead to 3 Pole connector and 2 x 3m data leads

UK Part Number: 90PD105196GST

  • Socket individually fused to 3.15A
  • 1m Mains lead to 3 pole connector
  • 3m Data lead

Colour

White/White Surround

1 x UK Power Socket, 1 x USB Socket (Data transfer) Power socket 3.15A individually fused with 1m mains lead to 3 Pole connector and 2m USB lead

UK Part Number: 90AV100001GST

  • Socket individually fused to 3.15A
  • USB Socket is for data transfer only
  • 1m Mains lead to 3 pole connector
  • 3m Data lead

Colour

Black/Black Surround

1 x UK Power Socket, 1 x USB Socket (Data transfer) Power socket 3.15A individually fused with 1m mains lead to 3 Pole connector and 2m USB lead

UK Part Number: 90AV100002GST

  • Socket individually fused to 3.15A
  • USB Socket is for data transfer only
  • 1m Mains lead to 3 pole connector
  • 3m Data lead

Colour

Grey/Grey Surround

1 x UK Power Socket, 1 x USB Socket (Data transfer) Power socket 3.15A individually fused with 1m mains lead to 3 Pole connector and 2m USB lead

UK Part Number: 90AV100003GST

  • Socket individually fused to 3.15A
  • USB Socket is for data transfer only
  • 1m Mains lead to 3 pole connector
  • 3m Data lead

Colour

White/White Surround

1 x UK Power Socket, 2 x USB Sockets (Data transfer) Power socket 3.15A individually fused with 1m mains lead to 3 Pole connector and 2 x 2m USB leads

UK Part Number: 90AV95978GST

  • Socket individually fused to 3.15A
  • USB Socket is for data transfer only
  • 1m Mains lead to 3 pole connector
  • 3m Data lead

Colour

Black/Black Surround

1 x UK Power Socket, 2 x USB Sockets (Data transfer) Power socket 3.15A individually fused with 1m mains lead to 3 Pole connector and 2 x 2m USB leads

UK Part Number: 90AV100004GST

  • Socket individually fused to 3.15A
  • USB Socket is for data transfer only
  • 1m Mains lead to 3 pole connector
  • 3m Data lead

Colour

Grey/Grey Surround

1 x UK Power Socket, 2 x USB Sockets (Data transfer) Power socket 3.15A individually fused with 1m mains lead to 3 Pole connector and 2 x 2m USB leads

UK Part Number: 90AV94022GST

  • Socket individually fused to 3.15A
  • USB Socket is for data transfer only
  • 1m Mains lead to 3 pole connector
  • 3m Data lead

Colour

White/White Surround

1 x UK Power Socket, 1 x RJ45 Cat6 Socket, 1 x USB Socket (Data transfer) Power socket 3.15A individually fused with 1m mains lead to 3 Pole connector, 3m data lead and 2m USB lead

UK Part Number: 90AV100005GST

  • Socket individually fused to 3.15A
  • USB Socket is for data transfer only
  • 1m Mains lead to 3 pole connector
  • 3m Data lead

Colour

Black/Black Surround

1 x UK Power Socket, 1 x RJ45 Cat6 Socket, 1 x USB Socket (Data transfer) Power socket 3.15A individually fused with 1m mains lead to 3 Pole connector, 3m data lead and 2m USB lead

UK Part Number: 90AV100006GST

  • Socket individually fused to 3.15A
  • USB Socket is for data transfer only
  • 1m Mains lead to 3 pole connector
  • 3m Data lead

Colour

Grey/Grey Surround

1 x UK Power Socket, 1 x RJ45 Cat6 Socket, 1 x USB Socket (Data transfer) Power socket 3.15A individually fused with 1m mains lead to 3 Pole connector, 3m data lead and 2m USB lead

UK Part Number: 90AV82656GST

  • Socket individually fused to 3.15A
  • USB Socket is for data transfer only
  • 1m Mains lead to 3 pole connector
  • 3m Data lead

Colour

White/White Surround

UK Part Number: Data Cables

3m Cat 6 data cable. Male to male connector.

UK Part Number: 161713

2m USB data cable. Male to male connector.

UK Part Number: 161239

2m HDMI data cable. Male to male connector.

UK Part Number: 161718
