Porthole IV is the latest addition to our Porthole range. Porthole IV has been designed to support international sockets and USB charging, either our new Type A and Type C (Adaptive Fast Charge) USB Charger or our Twin Port 4A (When one USB device is charging it can draw up to 4 Amps when a second device is connected the 4 Amps is shared between the two devices) USB Charger. Both are capable of charging all leading smartphones and tablets.

All housed within the main body making the whole unit compact, easily retrofitted and can be connected to our underdesk power modules (Elite+, Conti, Rotasoc).

Porthole IV Options

• Available in three colours, Black, White & Grey with matching trim
• Requires a separate mains lead if connected directly to a wall or floor socket
• USB charging with our twin port USB Type-A 4A Charger
• USB charging with our new twin port Type A and C USB Charger

Fixing

• Fits in a standard 80mm grommet hole
• Designed to fit any desk thickness between 12mm and 42mm
• Easy to install, incorporates an under desk, hand tightened barrel nut to fix unit in place

Safety

• All power sockets are shuttered for added safety
• Manufactured from flame retardant ABS plastic
• Complies with BS 5733 (UK)

Notes

• Cables: White and grey modules are supplied with white cables and black modules are supplied with black cables.
• Data Cables: CMD cannot accept any responsibility or liability for providing category 6 performance in products supplied. CMD cannot accept any responsibility or liability for providing HDMI performance in products supplied over 5m in length.
• Fuses: Only accessible after removal of equipment plug.
• Lead Lengths: All lead lengths are approximate and subject to tolerance. Lead lengths shown will be the conductor length and not the distance from the end of the module to the plug. For example, a 3m prewired power lead will be approximately 2.875m as 125mm will be internal for the termination. This is also applicable for data leads.
• Data fascias may be subject to colour change.
